途:

用于吹制低密度聚乙烯(LDPE)、高密度聚乙烯(HDPE)塑料薄膜。 可制成各种背心袋、平品袋、广泛应用于食品、服装、纺织、工业等包装。

点:

挤出机的机筒、螺杆均采用优质合金钢经氮化和精密加工。具有最佳硬 度和耐腐蚀性,本机组经科学设计一套挤出两付机头,提高生产量,节省能 源、劳动力、生产厂房等优点。

Use:

Used for blowing low density polyethylene (LDPE) and high density polyethylene (HDPE) plastic films. Can be made into various vest bags, flat bags, widely used in food, clothing, textile, industrial and other packaging.

Features:

The barrel and screw of the extruder are made of high-quality alloy steel after nitriding and precision processing. With the best hardness and corrosion resistance, this unit is scientifically designed with a set of two extruder heads to increase production, save energy, labor, and production plants

型号

Model

SJ-65FM-600

SJ-70FM-700

SJ-75FM-800

螺杆直径

Screw diameter

65mm

70m

75mm

螺杆长径比

Screw aspect ratio

28:1

28:1

28:1

螺杆转速

Screw speed

10-110r/min

10-110r/min

10-110r/min

最大产量

Maximum output

50kg/h

70Kg/h

90Kg/h

薄膜最大折径

Max folding diameter of film

550mm x 2

650mm x 2

750mm x 2

薄膜单面厚度

Film thickness

0.006-0.10mm

0.006-0.10mm

0.006-0.10mm

主机功率

monitor rate

18.5Kw

22Kw

30kw

总功率

Total power

40Kw

55Kw

70Kw

机器重量

Machine weight

3000kg

3800kg

4500kg

外形寸尺

Shape inch(mm)

5000×2900×3800

5300×3200×4700

5600×3400×4700
